Create a Custom Multi-Select Dropdown with Vanilla JavaScript

Add to your RSS feed24 January 20258 min read
Create a Custom Multi-Select Dropdown with Vanilla JavaScript

Table of Contents

Creating a custom multi-select dropdown enhances user experience and allows more flexibility than native <select> elements. Here's how you can build one from scratch with JavaScript, CSS, and HTML:

Step 1: Analyze Requirements

  • Allow users to select multiple options from a dropdown.
  • Display selected options in an input field.
  • Persist selections across page refreshes using localStorage.

Step 2: HTML Structure

Define the basic structure for the dropdown:

html
1 <div id="multiSelect" class="multi-select-dropdown"></div>

Step 3: CSS Styling

Style the dropdown for a clean, modern UI:

css
1 .multi-select-dropdown {
2     position: relative;
3     width: 300px;
4 }
5 .dropdown-header {
6     border: 1px solid #ccc;
7     padding: 10px;
8     cursor: pointer;
9     background: white;
10 }
11 .dropdown-list {
12     display: none;
13     position: absolute;
14     width: 100%;
15     max-height: 200px;
16     overflow-y: auto;
17     border: 1px solid #ccc;
18     border-top: none;
19     background: white;
20 }
21 .dropdown-list.show {
22     display: block;
23 }
24 .dropdown-item {
25     padding: 8px;
26     cursor: pointer;
27 }
28 .dropdown-item:hover {
29     background-color: #f0f0f0;
30 }
31 .dropdown-item.selected {
32     background-color: #e0e0e0;
33 }
34 .selected-tags {
35     display: flex;
36     flex-wrap: wrap;
37     gap: 5px;
38     margin-bottom: 5px;
39 }
40 .tag {
41     background-color: #f0f0f0;
42     padding: 2px 5px;
43     border-radius: 3px;
44     display: flex;
45     align-items: center;
46 }
47 .tag-remove {
48     margin-left: 5px;
49     cursor: pointer;
50 }

Step 4: JavaScript Logic

Implement the dynamic functionality:

js
1 class MultiSelect {
2   constructor(container, options) {
3       this.container = container;
4       this.options = options;
5       this.selectedValues = [];
6       this.render();
7       this.setupEventListeners();
8   }
9

10   render() {
11       // Create dropdown header
12       const header = document.createElement('div');
13       header.classList.add('dropdown-header');
14       header.textContent = 'Select options';
15

16       // Create selected tags container
17       const selectedTags = document.createElement('div');
18       selectedTags.classList.add('selected-tags');
19

20       // Create dropdown list
21       const list = document.createElement('div');
22       list.classList.add('dropdown-list');
23

24       this.options.forEach(option => {
25           const item = document.createElement('div');
26           item.classList.add('dropdown-item');
27           item.textContent = option.label;
28           item.dataset.value = option.value;
29           list.appendChild(item);
30       });
31

32       this.container.appendChild(selectedTags);
33       this.container.appendChild(header);
34       this.container.appendChild(list);
35   }
36

37   setupEventListeners() {
38       const header = this.container.querySelector('.dropdown-header');
39       const list = this.container.querySelector('.dropdown-list');
40       const selectedTags = this.container.querySelector('.selected-tags');
41

42       // Toggle dropdown
43       header.addEventListener('click', () => {
44           list.classList.toggle('show');
45       });
46

47       // Select/deselect items
48       list.addEventListener('click', (e) => {
49           if (e.target.classList.contains('dropdown-item')) {
50               const value = e.target.dataset.value;
51               const label = e.target.textContent;
52

53               if (this.selectedValues.some(item => item.value === value)) {
54                   // Deselect
55                   this.selectedValues = this.selectedValues.filter(item => item.value !== value);
56                   e.target.classList.remove('selected');
57               } else {
58                   // Select
59                   this.selectedValues.push({ value, label });
60                   e.target.classList.add('selected');
61               }
62

63               this.updateSelectedTags();
64           }
65       });
66

67       // Remove tag
68       selectedTags.addEventListener('click', (e) => {
69           if (e.target.classList.contains('tag-remove')) {
70               const valueToRemove = e.target.closest('.tag').dataset.value;
71               this.selectedValues = this.selectedValues.filter(item => item.value !== valueToRemove);
72               this.updateSelectedTags();
73               this.updateListSelection();
74           }
75       });
76

77       // Close dropdown when clicking outside
78       document.addEventListener('click', (e) => {
79           if (!this.container.contains(e.target)) {
80               list.classList.remove('show');
81           }
82       });
83   }
84

85   updateSelectedTags() {
86       const selectedTags = this.container.querySelector('.selected-tags');
87       const header = this.container.querySelector('.dropdown-header');
88

89       // Clear existing tags
90       selectedTags.innerHTML = '';
91

92       // Create new tags
93       this.selectedValues.forEach(item => {
94           const tag = document.createElement('div');
95           tag.classList.add('tag');
96           tag.dataset.value = item.value;
97           tag.innerHTML = `
98               ${item.label}
99               <span class="tag-remove">×</span>
100           `;
101           selectedTags.appendChild(tag);
102       });
103

104       // Update header text
105       header.textContent = this.selectedValues.length
106           ? `${this.selectedValues.length} selected`
107           : 'Select options';
108   }
109

110   updateListSelection() {
111       const list = this.container.querySelector('.dropdown-list');
112       list.querySelectorAll('.dropdown-item').forEach(item => {
113           const value = item.dataset.value;
114           if (this.selectedValues.some(selected => selected.value === value)) {
115               item.classList.add('selected');
116           } else {
117               item.classList.remove('selected');
118           }
119       });
120   }
121

122   // Optional method to get selected values
123   getSelectedValues() {
124       return this.selectedValues.map(item => item.value);
125   }
126 }
127

128 // Example usage
129 const options = [
130   { value: "1", label: "JavaScript" },
131   { value: "2", label: "TypeScript" },
132   { value: "3", label: "React" },
133   { value: "4", label: "Angular" },
134   { value: "5", label: "Svelve" },
135   { value: "6", label: "Vue" },
136 ];
137

138 const multiSelect = new MultiSelect(
139   document.getElementById('multiSelect'),
140   options
141 );

This code defines a class named MultiSelect that creates and manages a custom multi-select dropdown using vanilla JavaScript. It allows users to select multiple options from a dropdown and displays their selections with tags. Here's a breakdown of the key functionality:

Class Constructor

js
1 constructor(container, options) {
2   this.container = container;
3   this.options = options;
4   this.selectedValues = [];
5   this.render();
6   this.setupEventListeners();
7 }
  • container: A DOM element where the dropdown will be rendered.
  • options: An array of objects, each representing a dropdown option (value and label).
  • selectedValues: Tracks the currently selected items.

Calls:

  • render(): Renders the dropdown structure.
  • setupEventListeners(): Adds interactivity to the dropdown.

render Method

This method creates the visual structure of the dropdown:

  • Header: Displays the dropdown title or number of selected items.
  • Selected Tags Container: Displays tags for selected items.
  • Dropdown List: Lists all the available options dynamically from the options array.

Each option is rendered as a div with a data-value attribute containing the option's unique value.

setupEventListeners Method

Adds event listeners to enable dropdown functionality:

1. Toggle Dropdown:

js
1 header.addEventListener("click", () => {
2   list.classList.toggle("show");
3 });

Clicking the header toggles the visibility of the dropdown list.

2. Select/Deselect Items:

js
1 list.addEventListener("click", (e) => {
2   if (e.target.classList.contains("dropdown-item")) {
3     ...
4   }
5 });

Clicking an option:

  • Adds or removes it from selectedValues.
  • Toggles the selected class on the item.
  • Updates the tags using updateSelectedTags().

3. Remove Tags:

js
1 selectedTags.addEventListener("click", (e) => {
2   if (e.target.classList.contains("tag-remove")) {
3     ...
4   }
5 });

Clicking the remove icon (×) on a tag:

  • Removes the corresponding option from selectedValues.
  • Updates the tags and list selection.

4. Close Dropdown on Outside Click:

js
1 document.addEventListener("click", (e) => {
2   if (!this.container.contains(e.target)) {
3     list.classList.remove("show");
4   }
5 });

updateSelectedTags Method

Updates the selected tags displayed below the dropdown header:

  • Clears existing tags.
  • Adds a new tag for each selected item with a remove button.
  • Updates the header text to reflect the number of selected items or reset to "Select options."

updateListSelection Method

Synchronizes the dropdown list items with the current selections:

  • Adds the selected class to items in selectedValues.
  • Removes it from unselected items.

Optional getSelectedValues Method

Returns an array of the value properties of the currently selected options.

Example Usage

js
1 const options = [
2   { value: "1", label: "JavaScript" },
3   { value: "2", label: "TypeScript" },
4   { value: "3", label: "React" },
5   { value: "4", label: "Angular" },
6   { value: "5", label: "Svelte" },
7   { value: "6", label: "Vue" },
8 ];
9

10 const multiSelect = new MultiSelect(
11   document.getElementById("multiSelect"),
12   options
13 );
  • options: An array of programming languages/frameworks.
  • The dropdown is initialized on the container with the ID multiSelect.

Summary of Features

  • Allows multiple selections with tags to display selected options.
  • Dynamic rendering of dropdown options.
  • Toggleable dropdown list.
  • Click-to-select and deselect functionality for items.
  • Option to remove tags via a close (×) button.
  • Syncs UI with current selections.

This is a clean, reusable component that enhances usability by providing a multi-select dropdown built with pure JavaScript.

Full code

html
1 <!doctype html>
2 <html lang="en">
3   <head>
4     <meta charset="UTF-8" />
5     <title>Custom Multi-Select Dropdown</title>
6     <style>
7       .multi-select-dropdown {
8         position: relative;
9         width: 300px;
10         margin: 10rem auto;
11       }
12       .dropdown-header {
13         border: 1px solid #ccc;
14         padding: 10px;
15         cursor: pointer;
16         background: white;
17       }
18       .dropdown-list {
19         display: none;
20         position: absolute;
21         width: 100%;
22         max-height: 200px;
23         overflow-y: auto;
24         border: 1px solid #ccc;
25         border-top: none;
26         background: white;
27       }
28       .dropdown-list.show {
29         display: block;
30       }
31       .dropdown-item {
32         padding: 8px;
33         cursor: pointer;
34       }
35       .dropdown-item:hover {
36         background-color: #f0f0f0;
37       }
38       .dropdown-item.selected {
39         background-color: #e0e0e0;
40       }
41       .selected-tags {
42         display: flex;
43         flex-wrap: wrap;
44         gap: 5px;
45         margin-bottom: 5px;
46       }
47       .tag {
48         background-color: #f0f0f0;
49         padding: 2px 5px;
50         border-radius: 3px;
51         display: flex;
52         align-items: center;
53       }
54       .tag-remove {
55         margin-left: 5px;
56         cursor: pointer;
57       }
58     </style>
59   </head>
60   <body>
61     <div id="multiSelect" class="multi-select-dropdown"></div>
62     <script>
63       class MultiSelect {
64         constructor(container, options) {
65           this.container = container;
66           this.options = options;
67           this.selectedValues = [];
68           this.render();
69           this.setupEventListeners();
70         }
71

72         render() {
73           // Create dropdown header
74           const header = document.createElement("div");
75           header.classList.add("dropdown-header");
76           header.textContent = "Select options";
77

78           // Create selected tags container
79           const selectedTags = document.createElement("div");
80           selectedTags.classList.add("selected-tags");
81

82           // Create dropdown list
83           const list = document.createElement("div");
84           list.classList.add("dropdown-list");
85

86           this.options.forEach((option) => {
87             const item = document.createElement("div");
88             item.classList.add("dropdown-item");
89             item.textContent = option.label;
90             item.dataset.value = option.value;
91             list.appendChild(item);
92           });
93

94           this.container.appendChild(selectedTags);
95           this.container.appendChild(header);
96           this.container.appendChild(list);
97         }
98

99         setupEventListeners() {
100           const header = this.container.querySelector(".dropdown-header");
101           const list = this.container.querySelector(".dropdown-list");
102           const selectedTags = this.container.querySelector(".selected-tags");
103

104           // Toggle dropdown
105           header.addEventListener("click", () => {
106             list.classList.toggle("show");
107           });
108

109           // Select/deselect items
110           list.addEventListener("click", (e) => {
111             if (e.target.classList.contains("dropdown-item")) {
112               const value = e.target.dataset.value;
113               const label = e.target.textContent;
114

115               if (this.selectedValues.some((item) => item.value === value)) {
116                 // Deselect
117                 this.selectedValues = this.selectedValues.filter(
118                   (item) => item.value !== value
119                 );
120                 e.target.classList.remove("selected");
121               } else {
122                 // Select
123                 this.selectedValues.push({ value, label });
124                 e.target.classList.add("selected");
125               }
126

127               this.updateSelectedTags();
128             }
129           });
130

131           // Remove tag
132           selectedTags.addEventListener("click", (e) => {
133             if (e.target.classList.contains("tag-remove")) {
134               const valueToRemove = e.target.closest(".tag").dataset.value;
135               this.selectedValues = this.selectedValues.filter(
136                 (item) => item.value !== valueToRemove
137               );
138               this.updateSelectedTags();
139               this.updateListSelection();
140             }
141           });
142

143           // Close dropdown when clicking outside
144           document.addEventListener("click", (e) => {
145             if (!this.container.contains(e.target)) {
146               list.classList.remove("show");
147             }
148           });
149         }
150

151         updateSelectedTags() {
152           const selectedTags = this.container.querySelector(".selected-tags");
153           const header = this.container.querySelector(".dropdown-header");
154

155           // Clear existing tags
156           selectedTags.innerHTML = "";
157

158           // Create new tags
159           this.selectedValues.forEach((item) => {
160             const tag = document.createElement("div");
161             tag.classList.add("tag");
162             tag.dataset.value = item.value;
163             tag.innerHTML = `
164                     ${item.label}
165                     <span class="tag-remove">×</span>
166                 `;
167             selectedTags.appendChild(tag);
168           });
169

170           // Update header text
171           header.textContent = this.selectedValues.length
172             ? `${this.selectedValues.length} selected`
173             : "Select options";
174         }
175

176         updateListSelection() {
177           const list = this.container.querySelector(".dropdown-list");
178           list.querySelectorAll(".dropdown-item").forEach((item) => {
179             const value = item.dataset.value;
180             if (
181               this.selectedValues.some((selected) => selected.value === value)
182             ) {
183               item.classList.add("selected");
184             } else {
185               item.classList.remove("selected");
186             }
187           });
188         }
189

190         // Optional method to get selected values
191         getSelectedValues() {
192           return this.selectedValues.map((item) => item.value);
193         }
194       }
195

196       // Example usage
197       const options = [
198         { value: "1", label: "JavaScript" },
199         { value: "2", label: "TypeScript" },
200         { value: "3", label: "React" },
201         { value: "4", label: "Angular" },
202         { value: "5", label: "Svelve" },
203         { value: "6", label: "Vue" },
204       ];
205

206       const multiSelect = new MultiSelect(
207         document.getElementById("multiSelect"),
208         options
209       );
210     </script>
211   </body>
212 </html>

Conclusion

Creating a custom multi-select dropdown with vanilla JavaScript provides a powerful and flexible solution for enhancing user interfaces without relying on external libraries. By dynamically rendering elements, managing user interactions, and updating the UI in real time, this approach ensures a seamless and interactive experience. It also gives you full control over customization and functionality, making it adaptable to various use cases. Whether you're building a simple form or a complex application, mastering this technique is a valuable skill that showcases the versatility of JavaScript.

javascript
dropdown
multi-select

Related Posts:

Mastering Algorithm Complexity: Big O Notation Explained with JavaScript

Handling Base64 Encoding and Unicode Strings in JavaScript

Build a ShadCN UI Button Clone Component Using Vanilla JavaScript

Hide Data in PNG Files Using JavaScript: A Step-by-Step Guide

Understanding the Difference Between File and Blob Objects

getCookie vs document.cookie: Understanding the Differences

JavaScript Development Space
TelegramBskySubstackDailyDev

© 2025 JavaScript Development Space - Master JS and NodeJS. All rights reserved.
