Create a Custom Multi-Select Dropdown with Vanilla JavaScript

Creating a custom multi-select dropdown enhances user experience and allows more flexibility than native <select> elements. Here’s how you can build one from scratch with JavaScript, CSS, and HTML:

Step 1: Analyze Requirements

Allow users to select multiple options from a dropdown.
Display selected options in an input field.
Persist selections across page refreshes using localStorage.

Step 2: HTML Structure

Define the basic structure for the dropdown:

html

<div id="multiSelect" class="multi-select-dropdown"></div>

Step 3: CSS Styling

Style the dropdown for a clean, modern UI:

css

1234567891011121314151617181920212223242526272829303132333435363738394041424344454647484950

.multi-select-dropdown {
  position: relative;
  width: 300px;
}
.dropdown-header {
  border: 1px solid #ccc;
  padding: 10px;
  cursor: pointer;
  background: white;
}
.dropdown-list {
  display: none;
  position: absolute;
  width: 100%;
  max-height: 200px;
  overflow-y: auto;
  border: 1px solid #ccc;
  border-top: none;
  background: white;
}
.dropdown-list.show {
  display: block;
}
.dropdown-item {
  padding: 8px;
  cursor: pointer;
}
.dropdown-item:hover {
  background-color: #f0f0f0;
}
.dropdown-item.selected {
  background-color: #e0e0e0;
}
.selected-tags {
  display: flex;
  flex-wrap: wrap;
  gap: 5px;
  margin-bottom: 5px;
}
.tag {
  background-color: #f0f0f0;
  padding: 2px 5px;
  border-radius: 3px;
  display: flex;
  align-items: center;
}
.tag-remove {
  margin-left: 5px;
  cursor: pointer;
}

Step 4: JavaScript Logic

Implement the dynamic functionality:

class MultiSelect {
  constructor(container, options) {
    this.container = container;
    this.options = options;
    this.selectedValues = [];
    this.render();
    this.setupEventListeners();
  }

  render() {
    // Create dropdown header
    const header = document.createElement('div');
    header.classList.add('dropdown-header');
    header.textContent = 'Select options';

    // Create selected tags container
    const selectedTags = document.createElement('div');
    selectedTags.classList.add('selected-tags');

    // Create dropdown list
    const list = document.createElement('div');
    list.classList.add('dropdown-list');

    this.options.forEach(option => {
      const item = document.createElement('div');
      item.classList.add('dropdown-item');
      item.textContent = option.label;
      item.dataset.value = option.value;
      list.appendChild(item);
    });

    this.container.appendChild(selectedTags);
    this.container.appendChild(header);
    this.container.appendChild(list);
  }

  setupEventListeners() {
    const header = this.container.querySelector('.dropdown-header');
    const list = this.container.querySelector('.dropdown-list');
    const selectedTags = this.container.querySelector('.selected-tags');

    // Toggle dropdown
    header.addEventListener('click', () => {
      list.classList.toggle('show');
    });

    // Select/deselect items
    list.addEventListener('click', e => {
      if (e.target.classList.contains('dropdown-item')) {
        const value = e.target.dataset.value;
        const label = e.target.textContent;

        if (this.selectedValues.some(item => item.value === value)) {
          // Deselect
          this.selectedValues = this.selectedValues.filter(
            item => item.value !== value
          );
          e.target.classList.remove('selected');
        } else {
          // Select
          this.selectedValues.push({ value, label });
          e.target.classList.add('selected');
        }

        this.updateSelectedTags();
      }
    });

    // Remove tag
    selectedTags.addEventListener('click', e => {
      if (e.target.classList.contains('tag-remove')) {
        const valueToRemove = e.target.closest('.tag').dataset.value;
        this.selectedValues = this.selectedValues.filter(
          item => item.value !== valueToRemove
        );
        this.updateSelectedTags();
        this.updateListSelection();
      }
    });

    // Close dropdown when clicking outside
    document.addEventListener('click', e => {
      if (!this.container.contains(e.target)) {
        list.classList.remove('show');
      }
    });
  }

  updateSelectedTags() {
    const selectedTags = this.container.querySelector('.selected-tags');
    const header = this.container.querySelector('.dropdown-header');

    // Clear existing tags
    selectedTags.innerHTML = '';

    // Create new tags
    this.selectedValues.forEach(item => {
      const tag = document.createElement('div');
      tag.classList.add('tag');
      tag.dataset.value = item.value;
      tag.innerHTML = `
              ${item.label}
              <span class="tag-remove">×</span>
          `;
      selectedTags.appendChild(tag);
    });

    // Update header text
    header.textContent = this.selectedValues.length
      ? `${this.selectedValues.length} selected`
      : 'Select options';
  }

  updateListSelection() {
    const list = this.container.querySelector('.dropdown-list');
    list.querySelectorAll('.dropdown-item').forEach(item => {
      const value = item.dataset.value;
      if (this.selectedValues.some(selected => selected.value === value)) {
        item.classList.add('selected');
      } else {
        item.classList.remove('selected');
      }
    });
  }

  // Optional method to get selected values
  getSelectedValues() {
    return this.selectedValues.map(item => item.value);
  }
}

// Example usage
const options = [
  { value: '1', label: 'JavaScript' },
  { value: '2', label: 'TypeScript' },
  { value: '3', label: 'React' },
  { value: '4', label: 'Angular' },
  { value: '5', label: 'Svelve' },
  { value: '6', label: 'Vue' },
];

const multiSelect = new MultiSelect(
  document.getElementById('multiSelect'),
  options
);

This code defines a class named MultiSelect that creates and manages a custom multi-select dropdown using vanilla JavaScript. It allows users to select multiple options from a dropdown and displays their selections with tags. Here’s a breakdown of the key functionality:

Class Constructor

1234567

constructor(container, options) {
  this.container = container;
  this.options = options;
  this.selectedValues = [];
  this.render();
  this.setupEventListeners();
}

container: A DOM element where the dropdown will be rendered.
options: An array of objects, each representing a dropdown option (value and label).
selectedValues: Tracks the currently selected items.

Calls:

render(): Renders the dropdown structure.
setupEventListeners(): Adds interactivity to the dropdown.

`render` Method

This method creates the visual structure of the dropdown:

Header: Displays the dropdown title or number of selected items.
Selected Tags Container: Displays tags for selected items.
Dropdown List: Lists all the available options dynamically from the options array.

Each option is rendered as a div with a data-value attribute containing the option’s unique value.

`setupEventListeners` Method

Adds event listeners to enable dropdown functionality:

1. Toggle Dropdown:

123

header.addEventListener('click', () => {
  list.classList.toggle('show');
});

Clicking the header toggles the visibility of the dropdown list.

2. Select/Deselect Items:

12345

list.addEventListener("click", (e) => {
  if (e.target.classList.contains("dropdown-item")) {
    ...
  }
});

Clicking an option:

Adds or removes it from selectedValues.
Toggles the selected class on the item.
Updates the tags using updateSelectedTags().

3. Remove Tags:

12345

selectedTags.addEventListener("click", (e) => {
  if (e.target.classList.contains("tag-remove")) {
    ...
  }
});

Clicking the remove icon (×) on a tag:

Removes the corresponding option from selectedValues.
Updates the tags and list selection.

4. Close Dropdown on Outside Click:

12345

document.addEventListener('click', e => {
  if (!this.container.contains(e.target)) {
    list.classList.remove('show');
  }
});

`updateSelectedTags` Method

Updates the selected tags displayed below the dropdown header:

Clears existing tags.
Adds a new tag for each selected item with a remove button.
Updates the header text to reflect the number of selected items or reset to “Select options.”

updateListSelection Method

Synchronizes the dropdown list items with the current selections:

Adds the selected class to items in selectedValues.
Removes it from unselected items.

Optional `getSelectedValues` Method

Returns an array of the value properties of the currently selected options.

Example Usage

12345678910111213

const options = [
  { value: '1', label: 'JavaScript' },
  { value: '2', label: 'TypeScript' },
  { value: '3', label: 'React' },
  { value: '4', label: 'Angular' },
  { value: '5', label: 'Svelte' },
  { value: '6', label: 'Vue' },
];

const multiSelect = new MultiSelect(
  document.getElementById('multiSelect'),
  options
);

options: An array of programming languages/frameworks.
The dropdown is initialized on the container with the ID multiSelect.

Summary of Features

Allows multiple selections with tags to display selected options.
Dynamic rendering of dropdown options.
Toggleable dropdown list.
Click-to-select and deselect functionality for items.
Option to remove tags via a close (×) button.
Syncs UI with current selections.

This is a clean, reusable component that enhances usability by providing a multi-select dropdown built with pure JavaScript.

Full code

html

123456789101112131415161718192021222324252627282930313233343536373839404142434445464748495051525354555657585960616263646566676869707172737475767778798081828384858687888990919293949596979899100101102103104105106107108109110111112113114115116117118119120121122123124125126127128129130131132133134135136137138139140141142143144145146147148149150151152153154155156157158159160161162163164165166167168169170171172173174175176177178179180181182183184185186187188189190191192193194195196197198199200201202203204205206207208209210211212

<!doctype html>
<html lang="en">
  <head>
    <meta charset="UTF-8" />
    <title>Custom Multi-Select Dropdown</title>
    <style>
      .multi-select-dropdown {
        position: relative;
        width: 300px;
        margin: 10rem auto;
      }
      .dropdown-header {
        border: 1px solid #ccc;
        padding: 10px;
        cursor: pointer;
        background: white;
      }
      .dropdown-list {
        display: none;
        position: absolute;
        width: 100%;
        max-height: 200px;
        overflow-y: auto;
        border: 1px solid #ccc;
        border-top: none;
        background: white;
      }
      .dropdown-list.show {
        display: block;
      }
      .dropdown-item {
        padding: 8px;
        cursor: pointer;
      }
      .dropdown-item:hover {
        background-color: #f0f0f0;
      }
      .dropdown-item.selected {
        background-color: #e0e0e0;
      }
      .selected-tags {
        display: flex;
        flex-wrap: wrap;
        gap: 5px;
        margin-bottom: 5px;
      }
      .tag {
        background-color: #f0f0f0;
        padding: 2px 5px;
        border-radius: 3px;
        display: flex;
        align-items: center;
      }
      .tag-remove {
        margin-left: 5px;
        cursor: pointer;
      }
    </style>
  </head>
  <body>
    <div id="multiSelect" class="multi-select-dropdown"></div>
    <script>
      class MultiSelect {
        constructor(container, options) {
          this.container = container;
          this.options = options;
          this.selectedValues = [];
          this.render();
          this.setupEventListeners();
        }

        render() {
          // Create dropdown header
          const header = document.createElement('div');
          header.classList.add('dropdown-header');
          header.textContent = 'Select options';

          // Create selected tags container
          const selectedTags = document.createElement('div');
          selectedTags.classList.add('selected-tags');

          // Create dropdown list
          const list = document.createElement('div');
          list.classList.add('dropdown-list');

          this.options.forEach(option => {
            const item = document.createElement('div');
            item.classList.add('dropdown-item');
            item.textContent = option.label;
            item.dataset.value = option.value;
            list.appendChild(item);
          });

          this.container.appendChild(selectedTags);
          this.container.appendChild(header);
          this.container.appendChild(list);
        }

        setupEventListeners() {
          const header = this.container.querySelector('.dropdown-header');
          const list = this.container.querySelector('.dropdown-list');
          const selectedTags = this.container.querySelector('.selected-tags');

          // Toggle dropdown
          header.addEventListener('click', () => {
            list.classList.toggle('show');
          });

          // Select/deselect items
          list.addEventListener('click', e => {
            if (e.target.classList.contains('dropdown-item')) {
              const value = e.target.dataset.value;
              const label = e.target.textContent;

              if (this.selectedValues.some(item => item.value === value)) {
                // Deselect
                this.selectedValues = this.selectedValues.filter(
                  item => item.value !== value
                );
                e.target.classList.remove('selected');
              } else {
                // Select
                this.selectedValues.push({ value, label });
                e.target.classList.add('selected');
              }

              this.updateSelectedTags();
            }
          });

          // Remove tag
          selectedTags.addEventListener('click', e => {
            if (e.target.classList.contains('tag-remove')) {
              const valueToRemove = e.target.closest('.tag').dataset.value;
              this.selectedValues = this.selectedValues.filter(
                item => item.value !== valueToRemove
              );
              this.updateSelectedTags();
              this.updateListSelection();
            }
          });

          // Close dropdown when clicking outside
          document.addEventListener('click', e => {
            if (!this.container.contains(e.target)) {
              list.classList.remove('show');
            }
          });
        }

        updateSelectedTags() {
          const selectedTags = this.container.querySelector('.selected-tags');
          const header = this.container.querySelector('.dropdown-header');

          // Clear existing tags
          selectedTags.innerHTML = '';

          // Create new tags
          this.selectedValues.forEach(item => {
            const tag = document.createElement('div');
            tag.classList.add('tag');
            tag.dataset.value = item.value;
            tag.innerHTML = `
                    ${item.label}
                    <span class="tag-remove">×</span>
                `;
            selectedTags.appendChild(tag);
          });

          // Update header text
          header.textContent = this.selectedValues.length
            ? `${this.selectedValues.length} selected`
            : 'Select options';
        }

        updateListSelection() {
          const list = this.container.querySelector('.dropdown-list');
          list.querySelectorAll('.dropdown-item').forEach(item => {
            const value = item.dataset.value;
            if (
              this.selectedValues.some(selected => selected.value === value)
            ) {
              item.classList.add('selected');
            } else {
              item.classList.remove('selected');
            }
          });
        }

        // Optional method to get selected values
        getSelectedValues() {
          return this.selectedValues.map(item => item.value);
        }
      }

      // Example usage
      const options = [
        { value: '1', label: 'JavaScript' },
        { value: '2', label: 'TypeScript' },
        { value: '3', label: 'React' },
        { value: '4', label: 'Angular' },
        { value: '5', label: 'Svelve' },
        { value: '6', label: 'Vue' },
      ];

      const multiSelect = new MultiSelect(
        document.getElementById('multiSelect'),
        options
      );
    </script>
  </body>
</html>

Conclusion

Creating a custom multi-select dropdown with vanilla JavaScript provides a powerful and flexible solution for enhancing user interfaces without relying on external libraries. By dynamically rendering elements, managing user interactions, and updating the UI in real time, this approach ensures a seamless and interactive experience. It also gives you full control over customization and functionality, making it adaptable to various use cases. Whether you’re building a simple form or a complex application, mastering this technique is a valuable skill that showcases the versatility of JavaScript.

Create a Custom Multi-Select Dropdown with Vanilla JavaScript

Step 1: Analyze Requirements

Step 2: HTML Structure

Step 3: CSS Styling

Step 4: JavaScript Logic

Class Constructor

render Method

setupEventListeners Method

updateSelectedTags Method

updateListSelection Method

Optional getSelectedValues Method

Example Usage

Summary of Features

Full code

Conclusion

`render` Method

`setupEventListeners` Method

`updateSelectedTags` Method

Optional `getSelectedValues` Method
