🚀 Introduction

WebRTC (Web Real-Time Communication) is a powerful technology that allows browsers and mobile apps to exchange audio, video, and data in real-time — all without needing an intermediary server. It’s the backbone of modern video calls, screen sharing tools, and real-time collaboration platforms.

This article covers the full WebRTC pipeline: from accessing user media to establishing a secure peer-to-peer (P2P) connection, with practical TypeScript-flavored JavaScript examples.

🎥 Capturing Media Streams

What is a Media Stream?

A stream is a continuous flow of data — in WebRTC, that means audio or video in real time.

Capturing Audio and Video with getUserMedia

js
12345678910
      const constraints = { audio: true, video: true };

navigator.mediaDevices
  .getUserMedia(constraints)
  .then((mediaStream) => {
    console.log('Media stream received:', mediaStream);
  })
  .catch((err) => {
    console.error('Failed to get media:', err);
  });

💡 The browser will ask for user permission before providing access.

Displaying Video in a <video> Element

html
1
      <video autoplay playsinline id="local-video"></video>
ts
12345
      const videoElement = document.getElementById('local-video') as HTMLVideoElement;

navigator.mediaDevices.getUserMedia({ video: true }).then((stream) => {
  videoElement.srcObject = stream;
});

🎛 Listing and Selecting Devices

You can list all available input/output devices with:

ts
12345
      navigator.mediaDevices.enumerateDevices().then((devices) => {
  devices.forEach((device) => {
    console.log(`${device.kind}: ${device.label}`);
  });
});

🛠 To react to newly connected devices:

ts
123
      navigator.mediaDevices.addEventListener('devicechange', () => {
  console.log('Device list updated!');
});

🧪 Using Media Constraints

Want to select specific cameras or set video resolution?

ts
123456789101112131415
      const preferredDeviceId = 'abc123'; // from enumerateDevices()

const constraints = {
  video: {
    deviceId: { exact: preferredDeviceId },
    width: { ideal: 1280 },
    height: { ideal: 720 },
    frameRate: { ideal: 30 },
  },
  audio: {
    echoCancellation: true,
  },
};

navigator.mediaDevices.getUserMedia(constraints);

🖥 Capturing the Screen

ts
1234
      const screenStream = await navigator.mediaDevices.getDisplayMedia({
  video: true,
});
document.querySelector('video').srcObject = screenStream;

📌 Note: Browsers may prompt users to select a window or screen.

🎚 Managing Media Tracks

Each stream contains one or more tracks (audio/video). You can disable, stop, or access them individually:

ts
12345678
      const stream = await navigator.mediaDevices.getUserMedia({ video: true });
const tracks = stream.getTracks();

// Disable track
tracks[0].enabled = false;

// Stop track completely
tracks.forEach((track) => track.stop());

🌐 Establishing a Peer Connection

WebRTC’s RTCPeerConnection allows peers to connect directly:

ts
12345
      const config = {
  iceServers: [{ urls: 'stun:stun.l.google.com:19302' }],
};

const peerConnection = new RTCPeerConnection(config);

📡 ICE, STUN, TURN Explained

  • ICE: Helps find a working network path between peers.
  • STUN: Discovers public IP/port behind NAT.
  • TURN: Relays media if direct connection fails.

Example config with TURN:

ts
12345678910
      const config = {
  iceServers: [
    { urls: ['stun:stun.l.google.com:19302'] },
    {
      urls: 'turn:turn.example.com',
      username: 'user',
      credential: 'pass',
    },
  ],
};

🔄 ICE Candidate Exchange

ICE candidates must be exchanged manually via signaling (e.g., WebSocket):

Sending ICE candidates:

ts
12345
      peerConnection.onicecandidate = (event) => {
  if (event.candidate) {
    signalingServer.send('ice-candidate', event.candidate);
  }
};

Receiving:

ts
123
      signalingServer.on('ice-candidate', async (candidate) => {
  await peerConnection.addIceCandidate(candidate);
});

🤝 Offer/Answer Exchange (SDP)

Creating an offer:

ts
123
      const offer = await peerConnection.createOffer();
await peerConnection.setLocalDescription(offer);
signalingServer.send('offer', offer);

Handling offer:

ts
12345
      peerConnection.setRemoteDescription(offer).then(async () => {
  const answer = await peerConnection.createAnswer();
  await peerConnection.setLocalDescription(answer);
  signalingServer.send('answer', answer);
});

🎤 Adding Local Media to the Connection

ts
1234
      const stream = await navigator.mediaDevices.getUserMedia({ audio: true, video: true });
stream.getTracks().forEach((track) => {
  peerConnection.addTrack(track, stream);
});

Receiving remote media:

ts
1234
      peerConnection.addEventListener('track', (event) => {
  const remoteStream = event.streams[0];
  document.getElementById('remote-video').srcObject = remoteStream;
});

🔁 Dynamically Managing Tracks

Toggle microphone:

ts
1234
      const sender = peerConnection
  .getSenders()
  .find((s) => s.track?.kind === 'audio');
if (sender) sender.track.enabled = false; // or true

Add new track after connection:

ts
12
      const newTrack = stream.getVideoTracks()[0];
peerConnection.addTrack(newTrack, stream);

❌ Closing a WebRTC Connection

ts
12
      peerConnection.getSenders().forEach((sender) => sender.track.stop());
peerConnection.close();

👥 Group Calls: Mesh vs SFU vs MCU

Mesh

Each participant connects directly to all others. Simple, but CPU/network-intensive.

SFU (Selective Forwarding Unit)

Server forwards media without decoding. Lower client load.

Popular options:

  • LiveKit
  • mediasoup
  • Mirotalk

MCU (Multipoint Control Unit)

Server decodes and mixes streams. Lowest load on client, but higher latency and server cost.

🧩 Summary

WebRTC empowers real-time video/audio/data streaming with just a few lines of JavaScript. While simple to get started with, it involves deep concepts like ICE, SDP, and signaling.

Whether you’re building a Zoom alternative or live coding interviews — understanding how to capture, send, and receive streams peer-to-peer is the first step.
